JET 1015 Electronic Variable Speed Mini Wood Lathe
Ships from Jet, con US only. Does not qualify for free shipping
Description
The new JET 1015VS wood lathe is an ideal choice for the novice woodturner looking for an affordable, user-friendly first lathe, as well as the advanced enthusiast or professional who wants to add a full-featured mini-lathe to the shop.
This sturdy, smooth-running 15” mini-lathe has the power, precision, and versatility to turn out any number of projects. When you're ready to make your ideas a reality, and at a price you can afford... Start Here!
Jet 1015VS Mini Lathe Product Manual
Now available for pick up at our Racine, WI store!
(Other con US locations will add $50.00 large item delivery. Shipping from Racine WI, or from Mfgr)
1015VS WOOD LATHE FEATURES
- 15-1/2” between centers
- Six spindle speeds: 500, 840, 1240, 1800, 2630 and 3975
- Integrated 24 position indexing
- Improved tensioning system with easier access to belts
- Wider bed ways provide increased rigidity
- Live center in the tailstock
- 10" swing capacity
- Sturdy tool rest base
- No 2 Morse Taper
- Jet's Red Assurance 5 Year Warranty
- Optional stand and bed extension available
1015VS WOOD LATHE SPECIFICATIONS
- Swing Over Bed (In.) 10
- Swing Over Tool Rest Base (In.) 7-5/16
- Distance Between Centers (In.) 15-1/2
- Spindle Bore (In.) 3/8
- Spindle Taper MT2
- Quill Taper MT2 Quill Travel (In.) 2
- Spindle Thread (In./TPI) 1"/8 TPI
- Spindle Speeds 500/840/1240/1800/2630/3975
- Number of Indexing Positions 24
- Bed Construction Cast Iron
- Motor Power (HP) 1/2
- Motor Phase (PH) 1
- Motor Voltage (V.) 115
- Prewired Voltage (V.) 115
- Motor Amps 4
- Recommended Circuit Size (Amps.) 10
- Assembled Machine Dimensions (In.) 26L x 7W x 14H
- Weight 73 pounds / Shipping Weight 78 Pounds
